Plug Valve

Plug Valve
Plug Valve
Product Code : si-094
Brand Name : SUPREMO POLYMER
Product Description

Technical Specifications:

Size

25mm to 25O mm

Body

S.G.lron, WCB, CF8(SS 304) or CF8M(SS 316) Lined With FEP/PFA

Plug

ASTM A 216, Gr. WCB, CF8(SS 304) or CF8M(SS 316) Lined With FEP/PFA

Lining Material

FEP/PFA

Lining Thickness

3 to 5 mm THK.

Design

Single Piece As per BS- 5351

Temp. Resistant

FEP :-20 to 180* PFA :-20 to 230*

Testing

Hydro Test -11 kg /cm2 to Full Vacuum as per BS/API Pneumatic Test - 7 kg/cm2 Spark Test - 15 KVA DC

F to F

As per Class 150

Flange Drilling

As per ANSI B 16.5

Bill of Material

Body

ASTM A395 (DI) / ASTM A 216 (WCB) / SS 304

Plug

WCB / CB7 Cu1 / CF8 /CF8M

Lining

PFA ASTM D- 3307, PP, PVDF, FEP, ANTISTIC PFA AND HDPE AS PER STD

Testing Parameters as Per EN 12266-1

Hydro Test Body

AT 15.0 KG/CM2 AFTER LINING

Hydro Test Seat

AT 10.0 KG/CM2 AFTER LINING

Pneumatic Test

AT 06.0 KG/CM2 AFTER LINING

Spark Test

AT 15 KV DC AFTER HYDRO TEST

Lining Thickness

AS PER ASTM F 1545

Dimensions and Visual Check

100%

SIZE

L

25 NB

127

40 NB

165

50 NB

178

80 NB

203

100 NB

229

150 NB

267 (GEAR BOX)

200 NB

360 (GEAR BOX)
